The IES5100-24TS-P features 24x 10/100/1000BASE-T PoE+ ports, 8x 1G SFP ports, 4 x 10G SFP+ ports, which is designed especially for industrial applications. Equipped with an IP40 rated metal enclosure, it can operate within a wide temperature range of -40 to 75°C (-40 to 167°F). This switch is ideal for harsh environments, and can be widely used in energy, transportation, industrial production, environmental protection, and industrial industry. All Gigabit PoE+ ports support a power budget of up to 720W for PoE/PoE+, it is ideal for connecting PoE-powered end devices such as IP cameras, phones, wireless access points, sensors, and more. This layer 3 industrial switch supports enhanced functions such as L3 static routing, RIP, OSPF, VRRP, DHCP Server, etc., which can meet the requirements of many scenarios in industrial environments.
Description
24-Port Gigabit Ethernet L3 Managed Industrial PoE+ Switch, 24 x PoE+ Ports @720W, with 4 x 1Gb Combo, 8 x 1Gb SFP and 4 x 10Gb SFP+
| Ports |
20x 10/100/1000BASE-T RJ45 | 4x 1G RJ45/SFP Combo, 8x 1G SFP, 4x 10G SFP+
|
MAC Table Size
|
32K |
|
Switching Capacity
|
160Gbps |
Input Voltage
|
48‐57VDC |
|
Forwarding Rate
|
148,800pps/100M Ports 1,488,000pps/1000M Ports 14,880,000pps/10000M Ports
|
Power Budget
|
35W+720W (PoE) |
|
Flash Memory
|
32MB
|
Max. Power Consumption
|
35W (Without PD) |
|
Jumbo Frame
|
9,000
|
PoE Standard
|
IEEE 802.3af/at |
|
Packet Buffer
|
32Mb |
Operating Temperature
|
-40°F to 167°F (-40°C to 75°C) |
|
Dimensions (HxWxD)
|
1.72''x17.4''x13.19'' (43.8x442x335mm)
|
Storage Temperature
|
-40°F to 185°F（-40°C to 85°C)
|
|
Enclosure
|
IP40 Rated Metal Enclosure |
Operating Humidity
|
5-95%(non‐condensing)
|
|
Fan Number
|
Fanless |
Installation
|
Rack Mount |
|
Management
|
WEB GUI/SSH/Telnet/SNMP |
MTBF
|
≥ 600,000 Hours |
